Kubernetes as a service & Argo CD

Introduction

Initially, I wanted to learn something about apache airflow. After setting up a local kubernetes cluster with minikube, installing everything bare hands, I quickly realized that my local setup didn’t have enough power to really get going. Another issue with the manual workflow is that I had to make changes to the cluster and the deployments quite frequently.

Eventually, I decided to automate the wohle process of creating a kubernetes cluster and deploying an initial software stack.

In this post we will have a look how to create a kubernetes cluster with the LKE (Linode Kubernetes Engine) and how to deploy our software with Argo CD.

More details on airflow and how to leverage the power of kubernetes + airflow will follow in another post.

Other use cases to be explored would be handling heavy workloads with a highly performant, but short living, cluster. This could be batch workload or training a ML model with a GPU cluster.

Hopefully, I will be able to write another post about heavy batch workload with julia and my work in schemaitat/sparse_dot_topn_julia.

The kubernetes cluster

The main work for setting up the cluster and installing Argo CD is done in start.sh. The script is divided into eight steps (I) - (VIII). Setting up the cluster is done in steps (I) - (IV).

The first (and only) argument for the script is the path to a configuration yaml, which defines the cluster we want to create. An example would be:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

cluster: k8s-dev
kubernetes-version: 1.24
region: eu-central
tags:
- dev
- test
nodePools:
- type: g6-standard-2
  count: 1
- type: g6-standard-4
  count: 1

You can get a list of all types with costs by using linode-cli linodes types. The value of cluster is a unique name for the cluster. The cluster configuration will be parsed during step (I), the create-cluster step:

In step (II) we wait for the cluster to be ready. This is checked by waiting for all nodes in the cluster to be ready.

Note, that grep has a non-zero return code if no matches are found. That is why we enclose the while loop in set +e and set -e marks.

In step (III), after the cluster is ready, we copy the kubeconfig to our local machine. Note that the default location for the kubeconfig is defined in $KUBECONFIG.

1
2
3
4

export KUBECONFIG=~/${CLUSTER}-kubeconfig.yaml
log_notice "(III) Copying kubeconfig to $KUBECONFIG."
linode-cli lke kubeconfig-view $CLUSTER_ID --json --no-headers | jq '.[].kubeconfig' | sed 's|"||g' | base64 -D > $KUBECONFIG
chmod 700 $KUBECONFIG

In step (IV) we wait for the kubernetes api to be ready. This is necessary for the following steps and setting up Argo CD.

After having run steps (I) - (IV) you should have a running kubernetes cluster and a local copy of the kubeconfig accessible by kubectl.

Argo CD

Next, we will look at Argo CD. This is a deployment tool aiming to synchronize a certain state of an application. To this end we have a subfolder charts/argo-cd in our repository, which contains a so-called umbrella Helm Chart. This Helm Chart references to the original Argo CD Helm Chart, but also contains a customizable values.yaml.

Furthermore, we have a subfolder apps in our repository, containing a Helm Chart, which defines the root application. The root application contains templates, which are themselves applications. Since Argo CD tries to synchronize the root applicaiton, it will also synchronize every change made in any of the templates, e.g. the child applications.

The steps to install Argo CD and all applications in apps are:

1. Install Argo CD with helm using helm install.
2. By having an Argo CD application in the apps folder, Argo CD will eventually maintain itself.
3. Install the root application (with kubectl apply -f).

The idea of having a root application which synchronizes applications is called the app of apps schema. The dependencies look similar to

In this case Argo CD itself, Prometheus and Airflow are maintained by Argo CD and are installed after the root application is applied.

In our start.sh script, the just described steps are steps (V) - (VIII):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23

log_notice "(V) Creating namespaces"
namespaces="argocd monitoring airflow"
for ns in $namespaces; do
    kubectl create ns $ns
done

log_notice "(VI) Installing Argo CD"
# install argocd  and set up namespaces
helm dep update charts/argo-cd
helm install argo-cd charts/argo-cd/ -n argocd


log_notice "(VII) Waiting for all Argo CD deployments to be available"
#wait for argo cd to be deployed
argo_deployments=$(kubectl get deployments -n argocd --no-headers=true | awk '{print $1}')
for dep in $argo_deployments; do
    log_info "Waiting for deployment $dep to be available ..."
    kubectl wait deployment -n argocd $dep --for condition=Available=True --timeout=300s
done

log_notice "(VIII) Installing root application (app of apps)"
# install root application
kubectl apply -f apps/templates/root.yaml

In step (VII) we wait for Argo CD to be fully functioning. This ensures that Argo CD sees the root application just after it is truely able to install apps.

Tear down and cleanup

After having created a cluster with deployments, we eventually want to tear it down. This is quite easy with the linode cli, but we have to look out for possible artifacts, which are automatically created by Argo CD, most notably volumes.

The following script deletes the cluster and remembers volumes which had been attached to one of the nodes. After the cluster is deleted, the function delete_volume deletes the volume with given id. Unfortunately, to my current knowledge, there isn’t a neat way to check if a volume is still attached to a node. Thats why we “try” to delete the volume until it is detached.

In case this didn’t work for some reason, the script cleanup_volumes.sh tries to delete all volumes which have a null value for the node_id.
